    Deep Drawing 380V Metal Stamping Press Machine JW36 Automotive Stamping Press

    Ask Lasest Price
    Brand Name : WORLD
    Model Number : JW36
    Certification : CE ISO
    Price : Negotiation
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 20 sets per month
    Delivery Time : 45 working days
    • Product Details
    • Company Profile

    Deep Drawing 380V Metal Stamping Press Machine JW36 Automotive Stamping Press

    Mechanical Punch Press Machine Hydraulic Deep Drawing H Type Power Press Machine

    Features:

    1. Welded body with steel plate and high intensity.
    2.Main motor is made by Siemens.

    3. Adopts combined pneumatic friction clutch and brake.

    4 Cluster gear adopts the flooding oil lubrication

    5. Six-face rectangle lengthen guide

    6. Equipped with hydraulic overload protecting device

    7. Electric compelling grease lubrication system.
    8. Balancing cylinder adopts manual lubrication system.

    9. One set of blowing device

    10. Controlled by PLC with international brand

    11. Buttons, indicators, AC contactors, air circuit breakers and other controlling devices are imported from international brand

    12. Equipped with optional air cushion device, automatic feed shaft and photoelectric protector, which can used to work with various automatic equipments


    Standard equipment:
    Wet clutch(World)
    Hydraulic overload protecting pump
    Auto lubrication system
    Manual lubrication system
    Balance cylinders for slide and upper die
    Digital die height indicator Joint for miss-feeding
    Touch screen
    Electronic crankshaft angle indicator
    Cam controller
    Rotary encoder
    Movable operation panel
    Die height adjusted motor
    PLC:Programmable logical controller
    Air blowing device
    Shock Absorption Pads

    Optional equipments:
    Light curtain
    Foot pedal
    Air cushion device
    Die quick change device
    Frequency changer
    Knock out device (Shank Hole)
    Foundation bolts


    Specifications:

    ITEMCODEUNITJH25-110JH25-160JH25-200JH25-250JH25-315
    Nominal CapacityPeKN11001600200025003150
    Slide Stroke LengthSmm110130150170170
    Slide StrokesFixedspm6060504040
    Variable(optional)spm40-7040-7030-6030-4530-45
    Max. Die Shut HeightH2mm435550550605605
    Die Shut Height Adjustmenttmm90110110120120
    Throat DepthC1mm350390430470480
    Distance Between Uprightsd1mm14701600192021902170
    Slide Bottom SizeFBbmm520580650700700
    LRamm14001500185021002100
    Shank Hole SizeDiameterdmm6060707070
    DepthImm808590100100
    Table SizeFBDmm680760840920940
    LRCmm18802040242027002800
    ThicknessH3mm155165170180190
    Overall DimensionsFBAmm18202080237027002700
    LRBmm19702150255028502850
    HeightHmm32003380382041804180
    Motor PowerKW1118.5223037
